性能與特點：
采用鋼板焊接結構，液壓傳動，氮氣缸回程，操作方便，性能可靠，外形美觀。
刃口間隙調整有指示牌指示，調整輕便迅速。
設有燈光照明裝置，并能無級調節上刀架的行程量。
工作區采用柵欄式人身安全保護裝置。
后擋料尺寸及剪切次數有數字顯示裝置。
技術參數：
型號 | 剪板尺寸 | 剪切角（度） | 行程次數 | 后檔料架調節范圍 | 主電機 | 外型尺寸 |
QC12Y4x3200 | 4x3200 | 1°30′ | 18 | 20-600 | 5.5 | 3840x1675X1600 |
QC12Y6x2500 | 6x2500 | 1°30′ | 18 | 20-600 | 7.5 | 3130X1530X1600 |
QC12Y6x3200 | 6x3200 | 1°30′ | 14 | 20-600 | 7.5 | 3840X1675X1620 |
QC12Y6x4000 | 6x4000 | 1°30′ | 14 | 20-600 | 7.5 | 4630X1850X1700 |
QC12Y6x5000 | 6x5000 | 1°30′ | 10 | 20-800 | 18.5 | 5660X2050X1950 |
QC12Y6x6000 | 6x6000 | 1°30′ | 10 | 20-800 | 18.5 | 6700X2300X2300 |
QC12Y8x2500 | 8x2500 | 1°30′ | 14 | 20-600 | 11 | 3130X1530X1600 |
QC12Y8x3200 | 8x3200 | 1°30′ | 10 | 20-600 | 11 | 3840X1675X1620 |
QC12Y8x4000 | 8x4000 | 1°30′ | 8 | 20-600 | 11 | 3840X1850X1700 |
QC12Y8x5000 | 8x5000 | 1°30′ | 7 | 20-800 | 18.5 | 4630X2050X1950 |
QC12Y8x5000 | 8x6000 | 1°30′ | 6 | 20-800 | 18.5 | 6750X2330X2230 |
QC12Y10x2500 | 10x2500 | 1°30′ | 14 | 20-800 | 15 | 3130X1580X1800 |
QC12Y10x3200 | 10x3200 | 1°30′ | 12 | 20-800 | 15 | 3840X1725X1850 |
QC12Y10x4000 | 10x4000 | 1°30′ | 12 | 20-800 | 15 | 4630X1900X1850 |
QC12Y12x2500 | 12x2500 | 1°30′ | 16 | 20-800 | 18.5 | 3235X2045X1935 |
QC12Y12x3200 | 12x3200 | 1°30′ | 14 | 20-800 | 18.5 | 3945X2227X2115 |
QC12Y12x4000 | 12x4000 | 1°30′ | 14 | 20-800 | 18.5 | 4695X2227X2200 |
QC12Y12x5000 | 12x5000 | 1°30′ | 7 | 20-1000 | 45 | 6100X3370X3050 |
QC12Y12x6000 | 12x6000 | 1°30′ | 6 | 20-1000 | 45 | 7100X3370X3050 |
QC12Y12x8000 | 12x8000 | 1°30′ | 5 | 20-1000 | 45 | 9100X3575X3150 |
QC12Y16x2500 | 16x2500 | 2° | 16 | 20-650 | 18.5 | 3235X2050X1985 |
QC12Y16x3200 | 16x3200 | 2° | 12 | 20-800 | 22 | 3950X2230X2150 |
QC12Y16x4000 | 16x4000 | 2° | 10 | 20-800 | 22 | 4700X2230X2250 |
QC12Y20x2500 | 20x2500 | 2°30′ | 5 | 20-1000 | 37 | 3290X2900X2450 |
QC12Y20x3200 | 20x3200 | 2°30′ | 4 | 20-1000 | 37 | 4000X3100X2600 |
QC12Y20x4000 | 20x4000 | 2°30′ | 3 | 20-1000 | 37 | 4750X3300X2800 |
QC12Y20x6000 | 20x6000 | 2°30′ | 3 | 20-1000 | 75 | 7050X3480X3050 |
QC12Y25x2500 | 25x2500 | 2°30′ | 6 | 20-1000 | 45 | 3500X3150X3500 |
QC12Y25x3200 | 25x3200 | 2°30′ | 5 | 20-1000 | 45 | 4200x3150x3500 |
QC12Y25x4000 | 25x4000 | 2°30′ | 5 | 20-1000 | 45 | 4850x3300x3500 |
QC12Y32x2500 | 32x2500 | 3° | 5 | 20-1000 | 55 | 3500x3150x3500 |
QC12Y32x3200 | 32x3200 | 3° | 4 | 20-1000 | 55 | 4200x3150x3500 |
QC12Y40x2500 | 40x2500 | 4° | 5 | 20-1000 | 75 | 3600x3300x3200 |
QC12Y40x3200 | 40x3200 | 4° | 3 | 20-1000 | 90 | 4300x3300x3400 |
QC12Y50x3000 | 50x3000 | 3° | 5 | 90X3 | 4040X3600x4800 | |
QC12Y50x6000 | 50x6000 | 3° | 5 | 90X5 | 7040x2800x5100 | |
QC12Y60x3500 | 60x3500 | 3°30′ | 5 | 90X4 | 5600x3800x4900 |
